Test Lead Wire

Conductor : Tin-Plated Copper
Insulation : See table
Temperature Rating : 60°C
Operating Voltage : See table
Applications : For use as test leads on monitoring and testing equipment and as oscillator leads.

60°C

1 EPDM 75°C Available in Black or Red 2 90°C Black or Red 3 60°C Black or red (Also available in EPDM 75°C, Black, Red, Blue, Green, Gray)

Replace * with number from Color Code Chart “Hook Up Wire”

Showing all 4 results

SKU Wire Gauge Number of Strands Nominal Insulation Nominal Outside Diameter Operating Voltage Breakdown Voltage AC RMS Insulation
A83B17-* 20 41 0.04 0.09 1,500 6,000 Rubber
A83B17-* 20 41 0.025 2,500 10,000 PVC
A83B24-* 18 65 0.045 0.14 5,000 20,000 Rubber
A83B24-* 18 65 0.045 5,000 20,000 PVC
